KS-FAP625 is high RF power, high speed, high performance Wi-Fi6 outdoor wireless access point with SFP fiber port; With IP65 outdoor shell, Qualcomm IPQ5018 enterprise chipset, 2.4G+5.8G dual band, 3000Mbps data rate, support 802.1kvr seamless roaming, can access into 150+ users. With cloud central management system, it is high stability equipment for outdoor wireless coverage in sandy beach, scenic spot, park, playground ect...
Main Features:
Outdoor plastic+metal shell, IP65 protection level, can be installed in any harsh environment.
High performance enterprise CPU, world-wide branded electronic IC, allow 150+ users to access, performance better as the high quality.
The wireless data rate up to 3000Mbps, support 48V active PoE, so easy apply to various network environments to achieve fiber to wireless signal.
Support 802.11kvr seamless roaming, users automatically switch to high stability signal but no Wi-Fi dropping
Support WPA3 and 802.1x advance encryption, guard wireless network security all the time
Strong technical support, including customer LOGO or customer firmware development.
Hardware Spec: | |
Model | KS-FAP625 |
WiFi Standard | IEEE 802.11b/g/n/ac/ax |
CPU | IPQ5018 |
Flash | 8MB_SPI_NOR Flash+128MB_SPI_L NAND Flash |
Memory | 512MB |
Frequency | 2.4G: 2400 - 2484MHz |
5.8G: 5150 - 5850MHz | |
Data Rate | 600Mbps @ 2.4GHz; 2400Mbps @5.8GHz |
RF Power | 2.4G 11b≥27dBm/chain, 11n HT20≥24dBm/chain, 11ac HT40≥23dBm/chain, 11ax HT40≥17dBm/chain 5.8G 11n≥26 dBm/chain; 11ac≥23 dBm/chain; 11ax≥18 dBm/chain; |
Access Users | 150+ Clients |
Ethernet | 1*SFP port |
1*RJ45 port, support 802.3at PoE | |
Button | Reset button |
Antenna | External detachable 6dBi antenna |
Power Consumption | <23W |
Power Supply | PoE, IEEE 802.3at standard |
Water-Proof | IP65 protection level |
MTBF | ≥85000H@25℃ |
Working temperature | Working Temperature:-20℃~55℃ |
Storage temperature: -40℃~70℃ | |
Humidity | 5%~95% |
Firmware Features | |
Operation mode | AP and router |
Wireless Functions | Multiple SSID functions: 2.4GHz: 8; 5.8GHz: 8. |
Support 160MHz bandwidth | |
Support seamless roaming, 802.11kvr standard. | |
Support 5.8G Prior for a faster Ethernet. | |
Support MAC filter | |
Support client isolation to improve the wireless stability | |
VPN | Support PPTP, L2TP and OpenVPN if work with AC controller |
Security | Open, WPA, WPA2PSK_TKIPAES, WAP2_EAP, 802.1x, WPA3 |
IP Protocol | IPv4/IPv6 |
Device Management | GUI web management |
Support firmware back-up, restore, reset, upgrade | |
Packing List
| KS-FAP625*1 6dBi omni antenna*4 Cat 6 LAN Cable×1(1 meter) User Manual×1 |
