KS-5G-OM626 is an high speed outdoor 5G CPE with SIM card slot, Qualcomm chipset, maximum 3.4Gbps in 5G speed, plug and play, high gain antenna to enhance the 5G signal, provide more speed and very stable 5G network for users.
High speed 5G Network, plug and play
Compatible with NSA/SA dual-mode, more than 750Mbps 5G throughput, suits to all network types all over the world, plug and play, let’s enjoy the ultra-fast broadband connection at any places
PoE support
1*10/100/1000Mbps RJ45 port, support power over Ethernet, can be installed at places that far away from the power socket, besides that, it can provide Gigabit Ethernet for router/terminals.
High gain antenna and better 5G signal
Equipped with omni 5dBi antenna, easy to get the 5G signal all around, what’s more, it is detachable antenna as N type detachable connector, users can select the required 5G antenna based on their requirement.
High reliability
Adopt professional outdoor engineering plastic-aluminum shell, tightly sewn; It can prevent dust and water, adapt to harsh environment such as wind, frost, rain and snow, work as usual even in extreme high and low temperature environment.
More features such as VPN, eSIM, SIM lock, SMS, Phone book and TR069 support.
Hardware Spec: | |
Model | KS-5G-OM626 |
WCPU | MT7621AT |
Flash | 16MB |
Memory | 256MB DDR3 |
Interface | 1*10/100/1000Mbps RJ45 port |
1*SIM card slot for 5G SIM card | |
1* Reset button | |
System Status | |
Power Status | |
5G Antenna | Omni 5dBi 5G antenna |
Power Consumption | <15W |
Power Supply | 24V/1A PoE power |
Working temperature | Working Temperature:-20℃~55℃ |
Storage temperature: -30℃~70℃ | |
Humidity | 5%~95% |
Dimensions | 240mmX204mmX90.5mm |
4G/5G Speed | |
5G Chipset | Qualcomm X62 (Global Version) |
4G/5G Band | 5G: SA &NSA: n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/n66/n70/n71/n75/n76/n77/n78/n79; LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71; LTE-TDD: B34/B38/B39/B40/41/B42/B43/B48 WCDMA:B1/B2/B4/B5/B8/B19 |
4G/5G Speed | NSA TDD: Max. 3.4Gbps(DL)/550Mbps(UL); SA TDD: Max. 2.4Gbps(DL)/900Mbps(UL); LTE: 1.6Gbps(DL)/200Mbps(UL); UMTS: DC-HSDPA:42Mbps(DL) DC-HSUPS:5.76Mbps(UL); |
5G Chipset | Qualcomm X62 (Europe/Middle East/Brazil/Africa Version) |
4G/5G Band | 5G: SA &NSA: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n71/n75/n76/n77/n78 LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32/B71; LTE-FDD: B38/B40/B41/B42/B43; WCDMA:B1/B5/B8 |
4G/5G Speed | NSA TDD: Max. 3.4Gbps(DL)/550Mbps(UL); SA TDD: Max. 2.4Gbps(DL)/900Mbps(UL); LTE: 1.6Gbps(DL)/200Mbps(UL);UMTS: DC-HSDPA:42Mbps(DL) DC-HSUPS:5.76Mbps(UL); |
5G Chipset | Unisoc UDX710 (Asia/Middle East) |
4G/5G Band | 5G: NSA:n41/78/79; SA:n1/28/41/77/78/79 LTE-FDD: B1/B2/B3/B5/B7/B8/B20/B28; LTE-FDD: B34/B38/B39/B40/B41; WCDMA:B1/B2/B5/B8 |
4G/5G Speed | NSA: Max. 2.2Gbps(DL)/575Mbps(UL); SA: Max. 2Gbps(DL)/1Gbps(UL); LTE: 600Mbps(DL)/150Mbps(UL); UMTS: 42Mbps(DL)/11Mbps(UL); |
Firmware Features | |
Operation mode | Router/5G |
VPN | VPN Passthrough and VPN Client (L2TP PPTP) |
Security | Open, WPA, WPA2PSK_TKIPAES, WAP2_EAP, WPA3 |
TR069 | Support |
IP Protocol | IPv4/IPv6 |
Device Management | GUI web management |
Support firmware back-up, restore, reset, upgrade | |
Packing List
| KS-5G-OM626*1 PoE adapter×1(24V1A) Installation Accessory*1 Cat 6 LAN Cable×1(1 meter) User Manual×1 |
