KS-AC1000 is an large sized enterprise gateway based on CAPWAP protocol, with below specials:
Equipped with 7 Gigabit RJ45 port, support multiple WAN ports, WAN port load balancing, multi operator access, Ethernet backup and Network overlay, Strategic routing etc...
Support smart QoS, Internet behavior management, network firewall, VPN, SD-LAN, IPv6, VLAN, remote access control and management.
Maximum 1000 end users to access Ethernet, provide high speed network, protect against network storm, ensure the normal operation of the network.
Deploy to network, it can be used as the main router or bypass AC controller; Centrally to configure 500PCS AP at the same time; Then the administrator can remote monitor, manage and maintain this network after project acceptance, greatly saves the human and material cost.
KS-AC1000 support multiple authentication like SMS auth, Radius billing auth, portal auth, account auth, no auth... to realize advertising, promotional or notifications...
KS-AC1000 can work with indoor & outdoor wireless AP, which are widely used in Enterprise, Village, Hotel, Shopping mall, School, Hospital...
1. Industrial gateway
1.1 KS-AC1000 support PPPoE/DHCP/Static IP access, work with different ISP Ethernet access.
1.2 Support multiple Gigabit WAN ports, support load balancing, Ethernet backup, Network overlay, provide users with a more stable and faster network.
1.3 KS-AC1000 support policy routing based on IP address, MAC address, network interface, domain name and other rules.
2. VPN client and VPN server support
KS-AC1000 support multiple VPN protocol: L2TP/PPTP/IPSec/OpeVPN
Support VPN working diagram: site to site and client to site
Support access control based certificate, support sub certificates generation and distribution
3.Multiple authentication
KS-AC1000 support multiple authentication, such as SMS auth, account auth, phone number auth, 3rd party Radius billing; Portal auth... Meet with medium to large network coverage authentication, advertisement, promotion or notification requirements.
4. Cloud management and SD-LAN support
4.1 KS-AC1000 support cloud access for remote management and SD-LAN function; Very easy to manage this controller and connected wireless AP;
4.2 KS-AC10000 support SD-LAN
SD-LAN is a Local area network (LAN) built around the principles of software-defined networking;
There are key differences in topology, network security, application visibility and control, management and quality of service; Centralized cloud-based network management, it bring specific benefits of adaptability, flexibility, cost-effectiveness, and scales to wired and wireless access networks.
5. AP Management function
5.1 Zero configuration and grouping
Add a zero configuration group before access the wireless AP, then the wireless AP will automatically get the corresponding configuration from this group, simple and convenient; Administrator can add different group in the whole network, all wireless AP can obtain the configuration from this groups.
5.2 Intelligent channel analyzer
KS-AC1000 is built intelligent channel analyzer, wireless AP can detect and analyze the Wi-Fi channels, greatly help wireless AP to select the channel with least interference and achieve the most stable wireless coverage effect.
5.3 Automatically assign IP address to wireless AP
KS-AC1000 has a built-in DHCP server, which automatically assigns IP addresses to wireless AP, avoids the IP address conflicts, saves labor configuration costs.
6. Network topology automatic generated
A network topology map will be automatically generated based on the actual network connection status in the AC controller WEB interface.
7. VLAN, Seamless roaming, 5.8G Prior other functions
KS-AC1000 support real-time network speed monitoring, VLAN tag and VLAN truck, 802.11kvr seamless roaming, static IP, DDNS, 5.8G prior, IPv6
Model | KS-AC1000 |
Protocol | IEEE 802.3, 802.3u, 802.3ab TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS, IPsec, PPTP, L2TP, CAPWAP Protocol |
CPU | Intel@ Baytrail J1800 2.4GHz/1MB |
CPU type | Board Sticking |
Flash | DDR3 1333/1600 |
Flash size | Default: 2GB, Optional: 4~8GB |
Storage type | General hard disk, SSD, CF card, DOM |
Hard dish | 1 x SATAIII 2.5 inch hard disk, capacity is changeable |
SSD | 1 x M-SATA SSD, default: 8GB |
CF card | 1 x TYPEII CF card |
DOM | 1 x SATA DOM (share hard disk interface) |
Heat Dissipate | Super silent ball fan |
Ports | 5 x 10/100/1000Mbps LAN ports (can set to WAN port) |
1 x 10/100/1000Mbps WAN port | |
2 x USB2.0 Ports | |
1 x Console Port, 115200bps default baud rate | |
Display port | 1 X VGA Port (Optional) |
Reset Button | Control GPIO or BYPASS |
LED Indicator | 1 x Power Indicator (Green) 1 x Status Indicator (Orange) 2 x Bypass Indicator (Yellow) |
Power Switch | 1 x Power Switch |
Power | AC:90-264V @47-63HZ |
Watchdog | Support |
Power Consumption | 75W |
Dimension | 1U, 430mm*300mm*44mm |
Package Size | 545(L) * 415(W) * 180(H)mm |
Working Temperature | -0℃~50℃ |
Storage Temperature | -40℃ ~ 70℃ |
Working Humidity | 5% ~ 97%RH (No condensation) |
Firmware features | |
AP Management | Max to access and manage 1000 users |
Max to manage 500PCS wireless AP | |
Centrally and remotely to manage/configure wireless AP | |
User’s status checking | |
Smart Flow Control | No-configuration intelligent flow control |
Powerful multi-line diversion | |
Application Priority Automatically | |
Load Balance | Multiple WAN, multiple ISP network access |
Intelligence load balance | |
Ethernet line backup | |
Ethernet overlay | |
Policy routing: based on IP address, destination IP address, source MAC address, network port, domain, destination port, Extranet port, Identity binding | |
Protocol binding | |
Online detection | |
Routing | Static Routing |
Behavior Management | All-round to block P2P firmware |
P2P flow control and bandwidth allot | |
File and URL filter | |
Monitor network behavior at all times | |
VPN | L2TP, PPTP, OpenVPN, IPSec |
Bandwidth limitation | IP-based bandwidth limitation |
Safeguard / Restrict bandwidth | |
Time strategy | |
IP based session restriction | |
Security Center | MAC address filter |
UPR/key words filter | |
Web content filter | |
IP address filter | |
Port mapping | |
DMZ | |
Defense Center | TCP/UDP/ICMP flood defense |
Block TCP scanning | |
Block ping WAN port | |
ARP Detection | Send GARP packets |
ARP Scanning on WAN/LAN port | |
Online detection | |
IP-MAC binding | |
Authentication | Portal auth; 3rd Radius billing auth; Account auth, SMS auth; No auth... |
Management | Web/CLI/Telnet management |
Remote management | |
Others | DDNS, VPN management |
Content | KS-AC1000 *1 |
Power Cord *1 | |
Installation Accessory | |
QIG*1 |
